رکوردر دستی با کیفیت زوم ZOOM H5

0تومان

EVOLVED RECORDING
THE ZOOM H5
Flexible Audio for Video Perfection
Four tracks of simultaneous recording and interchangeable mic capsules make the H5 flexible and powerful enough to meet the evolving needs of today’s creators.

توضیحات

رکوردر دستی با کیفیت زوم مدل اچ 5 با قابلیت های بسیار قوی
از ويژگی های این رکوردر سازگاری با تمامی کپسول های شرکت زوم – 4 کانال صبط جداگانه صدا – 15 ساعت کارکرد با 2 عدد باتری -پشتیبانی از کارت های حافظه
SPECS
GENERAL
Recording media::
SD card: 16MB to 2GB , SDHC card: 4GB to 32GB

Display::
Backlit LCD (128 x 64 pixels)

INPUTS
INPUTS L/R [XYH-5 X/Y mic]::
Mic type: Unidirectional
Sensitivity: -45 dB, 1 kHz at 1 Pa
Input gain: -∞ to 52 dB
Max sound pressure input: 140 dB SPL

MIC/LINE IN ::
Connector: 1/8″ stereo mini jack
Input gain: – ∞ to 52 dB
Input impedance: 2 k Ω or more
Plug-in power: 2.5V supported
Backup recording: -12dB lower than set L/R input gain

INPUTS 1/2::
Connectors: XLR / TRS combo jacks
(XLR: Pin 2 hot / TRS: Tip hot)
Input gain (PAD OFF): -∞ to 55.0 dB
Input gain (PAD ON): -∞ to 35.0 dB
Input impedance: 1.8 k Ω or more
Max input level: +22 dBu (PAD ON)
Phantom power: +12V /+24V /+48V
Equivalent Input Noise (EIN): -120 dBu or less

OUTPUTS
LINE OUT::
Connector: 1/8″ stereo mini jack
Rated output level: -10 dBm
Output load impedance: 10k Ω or more

PHONE OUT::
400mw 8 Ω mono

RECORDING FORMATS
STEREO MODE::
WAV (BWF-compliant)
Sampling frequency: 44.1/48/96 kHz
Bit rate: 16/24 (Stereo)
Maximum simultaneous recording tracks: 2
MP3
Sampling frequency: 44.1kHz
Bit rate: 48/56/64/80/96/112/32/160/192/224/256/320kbps

MULTITRACK MODE::
WAV (BWF-compliant)
Sampling frequency: 44.1/48 kHz
Bit rate: 16/24 (Mono/Stereo)
Maximum simultaneous recording tracks: 6 (L/R + INPUT 1/2 + L/R backup)

USB
Mass Storage Class operation::
Class: USB 2.0 High Speed

Audio Interface operation: Multitrack mode::
Class: USB 2.0 High Speed
Sampling frequency: 44.1/48kHz
Bit rate: 16/24 bit
Inputs / Outputs: 4 / 2

Audio Interface operation: Stereo mode::
Class: USB 2.0 Full Speed
Sampling frequency: 44.1/48kHz
Bit rate: 16 bit
Inputs / Outputs: 2 / 2
USB bus powered operation possible
(iPad operation supported in Stereo mode only)

POWER REQUIREMENTS
AA size (LR6) battery x 2
AC adapter: AD-17 (DC5V/1A/USB-type) (optional)
USB bus power
